Wigwam visor
Wigwam visor
Wigwam Visor is a super premium grade product that conforms to marine, fire-retardant, and structural grades. Uniquely, it offers E0 formaldehyde emission levels that supplement a healthier lifestyle and is the First Indian Plywood to conform to Japanese F (add 4 stars here) Standards. It is preservative and is treated with the most reliable vacuum pressure impregnation to protect it from insects.
Available In
- 6mm
- 9mm
- 12mm
- 16mm
- 19mm
- 25mm
USPs and Features
- Structural Grade (IS:10701) certified.
- Also conforms to Fire Retardant Grade (IS:5509) and Marine Grade (IS:710)
- Immune to Termites
- Both Side Calibrated
- High Density of 780+ kg/m3
- Low Flammability
- Fire Resistance of 60 minutes
- Immune to Borers
- Double Surface Sanding for Superior Surface Finish
- Lesser Tendency to Spark and Ignite
- Lesser Smoke Generation
- Carb & EPA Certified E0 Certified
- Specially Formulated Fireproofing Chemicals Infusions
- Pre Composed Core and Panels to Reduce Gaps
- Slow Burning
- Immune to Microbes
- Super Premium Grade Product
- Higher Flame Penetration Time
- Decreased Chances of Fire to Spread over the Surface of the Plywood
- Lifetime Guarantee with 700% Cashback
Applications
- All Interior and Exterior Woodwork, Silos, Sheathing, Rail and Ship Containers, Plywood Web Beams, Stress Skin Panels, Ships, Bus Coaches, Cinema Halls, High Rise Buildings, Restaurants, Railway Coaches, Boiler Houses, Kitchens, Inner Roof Wall Linings, Exhibition Stalls, Public Places, Offices, Homes, etc.
Technical Specifications
Grade
Structural, FR, BWP
Face
Gurjan Face Veneer
Core
Gurjan/Pallaquillam/MLH
Length
+2~5 MM
Thickness Tolerance
+/-0.25 MM
Weather Calibrated
Both Side Calibrated
Fire Retardancy
90-120 mins
Edge Straightness
0.30%
No. of Ply
4MM - 3 Core 5 Ply(5 Layers), 6MM - 3 Core 5 Ply(5 Layers), 9MM - 5 Core 7 Ply(7 Layers), 12MM - 7 Core 9 Ply(9 Layers), 16MM - 11 Core 13 Ply(13 Layers), 19MM - 13 Core 15 Ply(15 Layers)
Core Gap
NIL on Top Core
Swelling (24 Hrs)
4% ~ 6%
Moisture Resistant Test
Conforms to IS 10701
Nail Holding Strength
Above 500 N
Species Used
Gurjan/Pallaquillam/MLH
Back
Gurjan Face Veneer
Size of Plywood
2440 x 1220 mm
Width
+2~5 MM
Face Veneer Thickness
0.40 MM
Glue Used
Fortified Phenol Formaldehyde (PF)
Squareness
0.30%
Density
780 kg/m3
Moisture Content
5% ~ 12%
Ply Overlap
NIL on Top Core
Swelling % (48 Hrs)
8% ~ 12%
Screw Holding Strength
Above 2000 N
Carb & EPA Certified E0
(with E0 - Less than 0.1 mg/L logo)
