Fabricate Club BWP
Wigwam Fabricate Club is made from hardwood timber and powered by calibration technology. The Gurjan Face Veneer adds an elegant touch to your interiors. Additionally, with a density of 750-800 kg/m3, Fabricate Club is the stronger plywood option.
Available In
- 4mm
- 6mm
- 9mm
- 12mm
- 16mm
- 19mm
- 25mm
USPs and Features
- Gurjan Face Veneer
- Immune to Microbes
- 100% Hardwood Timber
- E1 Emission
- Both Side Calibrated
- Boiling Water Proof
- Immune to Termites
- 30 Year-Guarantee with 300% Cashback
Technical Specifications
Grade
BWP
Face
Gurjan Face Veneer
Core
Eucalyptus
Length
+2~5 MM
Thickness Tolerance
+/-0.25 MM
Weather Calibrated
Both Side Calibrated
Edge Straightness
0.30%
No. of Ply
4MM - 3 Core 5 Ply(5 Layers), 6MM - 3 Core 5 Ply(5 Layers), 9MM - 5 Core 7 Ply(7 Layers), 12MM - 7 Core 9 Ply(9 Layers), 16MM - 9 Core 11 Ply(11 Layers), 19MM - 11 Core 13 Ply(13 Layers)
Core Gap
NIL on Top Core
Swelling (24 Hrs)
4% ~ 6%
Moisture Resistant Test
Conforms to Marine Grade (IS 710)
Species Used
Gurjan/Eucalyptus
Back
Gurjan Face Veneer
Size of Plywood
2440 x 1220 mm
Width
+2~5 MM
Face Veneer Thickness
0.30 MM
Glue Used
Phenol Formaldehyde (PF)/
Squareness
0.30%
Density
750 ~ 800 Kg/m3
Moisture Content
5% ~ 12%
Ply Overlap
NIL on Top Core
Swelling % (48 Hrs)
8% ~ 12%
